3 Unit Rack Summing Mixers



2in1 Neumann  56x16 TRS/TRS 4STM 28xCH INS SND

orchard studios summing unit

2in1 Active/Passive Neumann 56x16 TRS input /TRS out 4xSTM 4xMaster SND/RET, 24xChannel insert send, 8xOut control, Master Mono

Price: order

  • 3U Standard Rack unit
  • Neumann 475-2C NOS
  • 56input by TRS balanced
  • 8xStereo Master out by TRS balanced ABCDEFGH
  • Master out ON/OFF ABCDEFGH (8s switch) control
  • Master Active/Passive by switch
  • Master Send/Return by switch via TRS as:
  • SNDA/SNDB/SNDC/SNDD send/return
  • 4xStereo to Mono by switch = 8 mono
  • Master out Stereo to mono by switch
  • 2x21 step precision Neumann master gain potentiometer L/R
  • vintage style white cream knobs
  • 28xSend/Return on each stereo channel by DB25 Tascam Analog
  • Total SUM Bypass option on Stereo Ch1 (1/2) via 2xSwitch option
  • Unique name engraving: "designed for Orchard Studios by VintageMaker"
  • 110-240VAC to 18-24 VDC 0,6-1,5A PSU
  • Power Led: Blue
  • build time 22 business working weekdays (estimated)

Master Active/Passive 2in1 option: like You have 2 type of summing mixer in the box:



Stereo to Mono input switch: . youtube Stereo to Mono function



2in1 Neumann  40x4 TRS/TRS 4STM 20xCH INS SND

coyotools studio summing mixer

2in1 Active/Passive Neumann 40x4 TRS input /TRS out, 4xSTM Master SND/RET, 24xChannel insert send

Price: order

  • 3U Standard Rack
  • Neumann v475-2C NOS
  • 40 balanced input by TRS
  • 2xStereo Master out XLR
  • Insert/return Master by XLR
  • 4xStereo to mono on CH1-CH4
  • TRS Insert SEND from CH1 to CH10
  • *(copy of CH1-CH10 total 20 outputs)
  • TRS Insert/RETURN by switch from CH1 to CH10 total 20 inputs
  • *(include CH1-CH4 stereo to mono)
  • Designed and Built for COYOTOOLS STUDIO
  • 110-240VAC to 18-24 VDC 0,6-1,5A PSU
  • Power Led: Blue
  • build time 25 business working weekdays (estimated)

Master Active/Passive 2in1 option: like You have 2 type of summing mixer in the box:



  1. Active mixer: gain makeup by inside amp Neumann/Filtek/Lawo/NE2OX
  2. Passive mixer: gain makeup by Your external micpres or DAW amplifiers
  3. Benefits: Different amp = Different sound character

Master Send/Return option: SEND master audio signal to external EQ, Comp, Limiter



  • 2xSwitch version: You can Bypass Send/Return / or / Enable Send/Return by switch
  • Auto TRS version: signal was non iterrupted if nothing connected to SEND out TRS

Stereo to Mono input switch: . youtube Stereo to Mono function



Lawo 32x6 TRS/XLR/TRS 4STM SND/RET

Lawo 32x10 TRS input /XLR/TRS out 4xSTM Master SND/RET, 64xGROUP MATRIX Routing

Price: order

  • 3U Standard Rack
  • Lawo DV972
    32 in by TRS 1/4" balanced
    3xstereo out: Record XLR, Monitor TRS, 2nd monitor TRS balanced
    4xStereo to mono on CH1-CH4 = 8 mono by switch
    2x21 step precision gain control potentiometers black chicken head knobs
  • 2x21 Step precision Neumann master gain potentiometer white cream knobs
  • 4xStereo to mono switch = 8 mono on Master sum
  • 110-240VAC to 18-24 VDC 0,6-1,5A PSU
  • build time 22 business working weekdays (estimated)



2in1 Neumann  32x6 TRS/XLR 4STM 4xSUB GROUP SND

Lawo 32x6 TRS input /XLR/TRS out 4xSTM 4xMaster SND/RET, 4xSUB GROUP

Price: order

  • 3U Standard Rack unit
  • Neumann v475-2C NOS
  • 32 input by TRS balanced
  • 3xStereo out by XLR Balanced L/R
  • 1-8 TRS input balanced SND/RET by XLR via Front Switches
  • 9-16 TRS input balanced SND/RET by XLR via Front Switches
  • 17-24 TRS input balanced SND/RET by XLR via Front Switches
  • 25-32 TRS input balanced
  • 25-32 TRS SEND balanced /input signal always present on send TRS
  • 25-32 TRS RETURN by Front Return Enable/Bypass switch / 4xStereo CH
  • Master Active/Passive option by switch
  • Master Send/return by Switch via XLR Balanced
  • 4xStereo to mono = 8 mono on 25-32/ 4xStereo CH
  • 2x21 Step precision Neumann master gain potentiometer L/R
  • *white cream vintage knobs
  • Power Led: Blue
  • 110-240VAC to 18-24 VDC 0,6-1,5A PSU
  • build time 22 business working weekdays (estimated)



analog matrix summing mixer

What Is Analogue Warmth?


Not everyone has had first‑hand experience of magnetic tape recording and other analogue recording technology of course



but we've all heard and admired the vast back catalogue of classic records made using this technology from the 1950s onwards.



There are many factors:



that combine to create character in recordings, ranging from instruments, musicians and performances through the rooms and mics used, to the preamps, processors and effects (and the way in which they're used), but when we talk about analogue warmth, we're usually referring to the character that the analogue processing/recording equipment and the recording medium add to the sound.
